502 Inverted Flare Union Elbow

Product Features:
■■ All brass construction
■■ UL listed for flammable liquid and gas
■■ Meets functional requirements of SAE J512
■■ Steel nut for economy

Markets: Applications:
■■ Air Conditioning ■■ Refrigerant Lines
■■ Marine ■■ Brake Lines
■■ Mobile ■■ Fuel Lines
■■ Engines

Compatible Tubing:
■■ Copper
■■ Brass
■■ Aluminum
■■ Welded Steel Hydraulic Tubing

Reference Part No:
502 - 450

SPECIFICATIONS

PART#	TUBE O.D	D	M	L
502-4	1/4	.188	.53	.77
*502-5	5/16	.219	.59	.86
*502-6	3/8	.281	.72	1.04

*Not Standard

*Ref.SAE No.040201 BA

The 502 Inverted Flare Union Elbow is a flare union that provides a universally compatible connection for tubing on the downstream side of the part. It has all brass construction, is UL listed for flammable liquid and gas, and meets functional requirements of SAE J512. Steel nut for economy please check ref no.

This Union Elbow is a plumbing fitting used in refrigeration and air conditioning systems. It is typically connected to copper, silver or brass tubing. The flared fittings include drainage holes to help drain the condensation from the tubing.
